Revan LOR-VIB is a battery LoRaWAN vibration node for motors, pumps, fans and compressors. A 3-axis MEMS accelerometer reports ISO 10816-style velocity RMS (mm/s), acceleration RMS/peak and case temperature. On threshold it wakes immediately instead of waiting for the next period. Mount with an M8 stud or a neodymium magnetic base.
Electric motors and gearboxes, water/submersible pumps, industrial fans, compressors, crushers and bearing watch. Goal: see a vibration or heat trend before a trip.
The node sleeps, samples acceleration, computes velocity RMS in 10 Hz–1 kHz, adds temperature and sends Class A. Threshold wake-up skips the wait. OTAA/ABP. Range ±2/±4/±8/±16 g. The mounting face must be rigid; a loose magnet spoils the reading.
| Product | Revan LOR-VIB — battery LoRaWAN vibration & surface temperature |
|---|---|
| Parameters | Velocity RMS (10 Hz–1 kHz), accel RMS/peak, temperature |
| Temperature | −40°C … +85°C (1°C) |
| Acceleration | ±2 / ±4 / ±8 / ±16 g |
| RF | LoRaWAN Class A, EU868, OTAA / ABP |
| Battery | ER14505; sleep < 2 µA; 3–5 years at 1 sample/h |
| Mounting | M8 stud or neodymium magnet |
| Ingress | IP67 / IP68 |
ISO 10816 depends on machine class and the mounting point. This is not a lab analyser; full FFT spectra are not sent over LoRaWAN.
Prefer the bearing cap, axis-aligned, on bare metal. Stay out of guards and rotating parts. LOTO if the machine stays live. Not a SIL vibration switch replacement.
LOR-VIB node and cell. M8 stud or magnetic base is chosen on order.
LOR-TH is climate/PT100/door. LOR-VIB is machine vibration and surface temperature.
Contact Revan Technology for quoting and alarm setpoints.
